After several months of joint effort, Victrex and the National Institute for Aviation Research (NIAR) at Wichita State University
have developed material and process specifications for Automated Fiber Placement systems
(AFP) according to NCAMP protocol.
NCAMP, the National Center for Advanced Materials Performance, works with the FAA
and industry partners to qualify material systems and populate a shared materials
database that can be viewed publicly.
NIAR’s Advanced Technologies Laboratory for Aerospace Systems (ATLAS) has begun manufacturing
test panels using VICTREX AE250 PAEK (polyaryletherketone), a thermoplastic material
system reinforced with IM7 carbon fibers. This is a part of the Modeling for Affordable Sustainable Composites (MASC) program, sponsored by the Air Force Research Laboratory. MASC focuses on developing
a certification framework for enabling novel materials and advanced structural concepts
used for automated manufacturing technologies.
This is the first time a program has conducted an in-depth investigation into the
variability of multiple AFP machines on the composite allowables generated using industry-standard
statistical procedures outlined in Composite Materials Handbook 17.
The project includes qualification of several thermoset, thermoplastic and dry-fiber
AFP material systems from Hexcel, Solvay, Toray, and Victrex. All of the data and
associated documents will be included in the NCAMP shared material database.
In order to mitigate risks due to machine variability, a series of pre-qualification
manufacturing trials were conducted to develop machine programming protocols to manufacture
equivalent panels across various AFP machines. These machine agnostic allowables can
then be used by a wide variety of certification programs regardless of the type of
AFP machines used for production. The AFP panel manufacturing kick-off was witnessed
by NCAMP airworthiness representatives and personnel from the Air Force Research Laboratory
and Victrex.
